DAP | D2351 | IMIX-7.3 | 7-channel 2U install mixer - 3 zones

The DAP IMIX-7.3 is a compact installation mixer with zone control. It has exact the same functionality as the IMIX-7.1 but each input on the IMIX-7.3 can be routed to the desired output. This function makes it possible to control 3 areas with different music, sound level and EQ settings.

Technical specifications
Mono Inputs: 2
Stereo Inputs: 10
Phono Audio Inputs: 2
Auxiliary Inputs: 1
Main Outputs: 3
Headphone Output: 1
Record Output: 1
THD Level: < 0.05 %
Frequency Response Minimum: 20 Hz
Frequency Response Maximum: 20000 Hz
Parametric Microphone Equalizer: 3 Bands
Parametric Main Equalizer: 3 Bands
Power Supply: 240 VAC 50-60 Hz
Power Consumption: 19.1 W
Height (mm): 88 mm
Width (mm): 95 mm
Length (mm): 481 mm
