DAP | D3915 | Odin CL-4 Connect | Network interface

The DAP Odin Line Array Series is a versatile sound system suitable for high-energy indoor and outdoor events for up to 2500 visitors. It is a scalable and rental-friendly solution for both stackable and suspended setups, suitable for almost any venue of any size. Odin systems have a robust design and can deliver incredible sound quality at an unprecedented low price. With DAP Odin, DJs, bands, actors and other performers can quickly and easily create deep, punchy bass, subtle instrument details and true vocal emotions.

The Odin Active Series is a collection of active line array satellites (T-8A), active line array subwoofers (S-18A and S-218A) and active full-range speakers (SF-12A and SF-15A). The DSP settings of each loudspeaker (group) in a setup can be adjusted from a laptop via a network. Up to 48 units can be connected to the CL-4 network interface. Celestion components, DSP optimisation and Class D amplifiers ensure excellent sound quality in any location and setup.

Multiple stacking and hanging solutions are available with dedicated fly bars, stack bars, pole mount adapters and fly towers. Safe transportation/storage is also ensured with dedicated flight cases, transport covers and castor boards. IP covers protect your speakers from heavy rain, making them a reliable and trustworthy companion in all conditions.

The DAP Odin CL-4 Connect lets you adapt the sound reproduction of your active DAP Odin installation to meet a high quality audio at any venue. It allows you to make adjustments, such as EQ, gain and delay, for each speaker or groups of speakers up to 48 units (12 per port). Each Odin active speaker and active subwoofer is equipped with fixed presets and 1 adjustable DSP preset. The adjustable DSP preset can be used to finetune settings in detail, as each location poses a different environment. For this, you'll need the Odin CL-4 in combination with Odin Editor Software, which is running on any Windows PC or laptop.

In addition to changing the DSP settings, the software allows you to monitor the input signal, clip/amp status, high/low response and temperature per active speaker/speaker group.

Technical specifications
Data Connector In: RJ45
Data Connector Out: RJ45
Power Connector In: Low Voltage DC plug
Power Consumption: 5 W
Height (mm): 46 mm
Width (mm): 197 mm
Length (mm): 135 mm
Weight: 1.04 kg
Material: Steel
IP Rating: IP20 (indoor use only)
