DMT | 101205 | DLD-72 MKII | Dual 7" Display with HDMI link - rack mount version

The DMT DLD-72 MKII is a professional rack mount double monitor system. It can be used for VJ monitoring, surveillance systems and any other multimedia setup where monitoring is necessary. It can be used for VGA, CVBS and HDMI sources. Because of the link outputs it is possible to make a daisy chain setup with the DLD-72 MKII. The built-in distributor guarantees a HDMI signal without signal loss. Both screens are individual with separate menus to set your desired settings for each screen.

Technical specifications
HDMI 1.3: 2
VGA (In): 2
CVBS Input Impedance: 75 Ω
Analogue Video Input: BNC / RCA
HDMI 1.3 (Loop): 2
VGA (Out): 2
CVBS Output Impedance: 75 Ω
Analogue Video Output: BNC / RCA
Display: TFT
Display Resolution (Horizontal): 800 px
Display Resolution (Vertical): 480 px
Display Size: 7"
Maximum Input Resolution: 1920 x 1080
Power Supply: 100-240 V AC 50-60 Hz
Power Consumption: 25 W
Power Connector In: IEC
Height (Including Handles): 133 mm
Width (Including Handles): 482.6 mm
Width (Without Handles): 440 mm
Depth (Without Handles): 78 mm
Rack Units: 3 U
