Product description:

The Neutrik NL8MPRXX-BAG is an 8-pole male chassis connector with a tough black metal housing in a square G size. Designed for panel mounting, this connector features recessed mounting holes and 4.8x0.5mm flat tabs. Thanks to its certification according to IEC 61984, this connector is accepted in audio devices designed according to IEC 62368-1.

The speakON panel mount connectors are among the standard chassis connectors for speaker and amplifier interconnections and feature a unique metal locking system that makes contact only when fully locked. The receptacles are robust, versatile and easy to mount.

Product Information:

• Title: NL8MPRXX-BAG
• Gender: Male

Electrical Information:

• Contact Resistance: ≤ 2 mΩ
• Dielectric Strength: 1.5 kVac
• Insulation Resistance: > 0.1 GΩ (after vapour heat)
• Rated Current per Contact: 30 A rms continuous (according to IEC 61984)
• Rated Voltage: 250 V AC
• Attention: speakON is NOT to be used as a mains or power supply connector (AC / DC)!

Mechanical Information:

• Lifetime: > 5000 mating cycles
• Termination: 3/16" flat tabs
• Locking Device: Quick Lock
• Mounting Direction: Rear / front mounting
• Chassis Shape: Square G-size flange
• Layout: Four thru holes

Material Information:

• Contact Plating: Ag (Silver)
• Contacts: Copper Alloy
• Shell: Zinc diecast, black chrome plated
• Insert: Polyamide (PA 6.6)

Environmental Information:

• Temperature Range: -30 °C to +80 °C
• Flammability: UL 94 V-0
