Novastar | 101619 | MCTRL-700 | Sender Box

The Novastar MCTRL-700 is a 6-output sender box for easily setting up your LED screen, suitable for fixed and mobile installations. Its HDMI and DVI input ensure an easy and reliable connection for playing your content on your LED screen without big hassles. Configured settings can be saved for plug-and-play use. One Novastar MCTRL-700 can handle up to 2.3 million pixels with a maximum resolution of 1920 x 1200. Multiple units can be cascaded to form one uniform control in case you need to control more pixels.

Technical specifications
Stereo Inputs: 1
Stereo Input Connector: TRS balanced 3.5 mm
HDMI 1.3: 1
Single Link DVI: 1
Main Outputs: 6
HDMI 1.3 (Loop): 1
Single Link DVI (Loop): 1
Scaling Function: No
GenLock: No
Maximum Loading Capacity: 2.3 Mpx
Maximum Input Resolution: 1920 x 1200
Control Options: USB
Power Supply: 100-240 V AC 50-60 Hz
Power Consumption: 12 W
Power Connector In: IEC
Data Connector Out: RJ45
