Showtec | 44510 | Pixel Controller | For Pixelstrip 20/40, Pixeltube 16/32 and Pixel Dot 1

The Showtec Pixel Controller is an easy-to-use four-output RGB pixel controller with dimmer function, suitable for controlling a variety of Pixel products, like the Pixelstrip 20/40, Pixeltube 16/32 and Pixel Dot. This controller is not only externally controllable by DMX, Master/Slave, Art-Net and Kling-Net, but can also be used as a stand-alone controller with built-in programs. Each of the 4 outputs can handle up to 4 m (13.1 ft) Pixelstrip, 5 m (16.4 ft) Pixeltube and 40 Pixel Dots. When using Art-Net, you are able to gain full control of all pixels to create stunning effects.

Technical specifications
DMX Channels: 7 / 480 / 1920
Power Supply: 100-240 V AC 50-60 Hz
Output Voltage: 24 V DC
Power Consumption: 320 W
Power Connector In: Power Pro Blue
Power Connector Out: Power Pro Grey
Height (mm): 342 mm
Width (mm): 210 mm
Depth (mm): 68 mm
Weight: 2.1 kg
IP Rating: IP20 (indoor use only)
Housing: Metal
Colour: Black
