Showtec | 50396 | Single DP-1 | 1-Channel DMX Dimming / Switch Pack

One channel DMX Dimming/Switch Pack
• 512 DMX-channels
• Wall / Truss mounting
• 50 mm dimming slider
• Dim and switch
• Dimming pre-set
• Dimming limit
• Capacitive load 10 A, Inductive load 3 A.

Technical specifications
Control Mode: DMX / Manual
DMX Channels: 1
Power Supply: 240 V AC 50-60 Hz
Output Current per Channel: 10 A
Power Connector In: Schuko Plug
Power Connector Out: Schuko Socket
DMX Connector In: XLR 3P
DMX Connector Out: XLR 3P
Length (mm): 100 mm
Width (mm): 80 mm
Height (mm): 195 mm
Weight: 1.4 kg
IP Rating: IP20 (indoor use only)
Housing: Metal
Colour: Gray
